Specification ¡P Video Amplifier Bandwidth: 2.25 GHz ¡P Single Link Range: 1080p ~ 1440p 2560 x 1440p ¡P Deep Color: 12 bits ¡P Vertical Frequency Range: 50 - 85 Hz ¡P Wide Frequency Range: 25MHz ~ 165MHz ¡P HDMI Input/Output Connector: TYPE A 19pin ¡P Power Consumption: 5 Watts (max.) ¡P Dimensions: 180 x 65 x 25 mm ¡P Weight: 250 g
Features ¡P Supports 4 inputs to 2 single- or dual-link DVI/HDMI (HDMI V-1.3a) outputs. ¡P Compatible with HDMI V-1.3a or DVI-D, HDCP-enabled HDTVs. ¡P Each port supports HDMI or DVI inputs (both Video and Audio signals). ¡P Supports high video resolution up to 2560 x 1440 with 12 bit color depth. ¡P Supports 2.25Gbps signaling rate for 480i/p, 720i/p, 1080i/p and 1440i/p up to 12-bit color depth. ¡P Supports multiple HD displays for multiple sources, such as HD-DVD players, HDMI enabled PCs or Notebooks, Digital Projectors, PlayStation 3, A/V Receivers and Set Top Boxes. ¡P Encloses a Remote Control for operational flexibility, easy control and convenient use. ¡P Eliminates a hassle for disconnection and reconnection with different sources. ¡P LED indications for operation/power modes. |
